LQH32PZ100MNCL SMD Inductor
LQH32PZ100MNCL SMD Inductor
Product Overview LQH32PZ100MNCL SMD Inductor Specifications of LQH32PZ100MNCL SMD Inductor Inductance : 10µH ±20% Inductance test frequency : 1MHz Rated current (Isat) (Based on Inductance change) : 1000mA Rated current (Itemp) (Based on Temperature rise) 900mA(Ambient temp.85℃) 450mA(Ambient temp.105℃) Max. of DC resistance : 0.354Ω Avg. of DC resistance : 0.295Ω ±20% Self resonance frequency (min.) : 30MHz Operating temperature range (Self-temperature rise is included) : -40℃ to 125℃ Operating temperature range (Self-temperature rise is not included) : -40℃ to 105℃ Class of magnetic shield : Magnetic Resin Series : LQH32PZ_NC Download Datasheet For more info please click here SKU: LC-51 Category: Inductors
Reviews
